Product Details
Place of Origin: Shandong, China
Brand Name: Lu Young
Certification: ISO CE
Payment & Shipping Terms
Price: $17,500.00/sets 1-1 sets
Packaging Details: 1.Non-fumigation packaging, we use seaworthy plywood.
2. Steel base plate, it is stronger 3-5 times than normal plywood base plate.
3.Water-proof and damp proof, water resistant film wraped all the machine.
4.Fully sheathed case,prevention of coll
|
Condition:
|
New
|
Spindle Taper:
|
BT40
|
No. Of Spindles:
|
Single
|
Type:
|
VERTICAL
|
Dimension(L*W*H):
|
1900*1400*2100
|
Weight (T):
|
2.4 T
|
Table Size (mm):
|
800*260
|
Number Of Axes:
|
3, 4, 5
|
Table Travel (X) (mm):
|
450
|
Table Travel (Y) (mm):
|
320
|
Table Travel (Z) (mm):
|
420
|
Positioning Accuracy (mm):
|
±0.01
|
Repeatability (X/Y/Z) (mm):
|
±0.003
|
Range Of Spindle Speed(r.p.m):
|
1 - 8000 R.p.m
|
Spindle Motor Power(kW):
|
3.7/5.5
|
Max. Table Load(kg):
|
200 Kg
|
Min. Time Of Tool Change(s):
|
7
|
Tool Magazine Capacity:
|
16, 10, 12
|
Key Selling Points:
|
High Safety Level
|
Warranty:
|
1 Year
|
Voltage:
|
380V 50HZ /220V 60 HZ
|
Marketing Type:
|
New Product 2020
|
Machinery Test Report:
|
Provided
|
Video Outgoing-inspection:
|
Provided
|
Warranty Of Core Components:
|
1 Year
|
CNC Or Not:
|
CNC System
|
After-sales Service Provided:
|
Engineers Available To Service Machinery Overseas
|
Travel Of X Axis(mm):
|
450
|
Travel Of Y Axis(mm):
|
320
|
Travel Of Z Axis(mm):
|
420
|
Max Speed Of Spindle (Rpm):
|
60-8000
|
Positioning Accuracy:
|
±0.01
|
Local Service Location:
|
None
|
Applicable Industries:
|
Building Material Shops, Machinery Repair Shops, Manufacturing Plant
|
Showroom Location:
|
None
|
Core Components:
|
Motor
|
Feed Speed(mm/min):
|
1 - 4000 Mm/min
|
Rapid Feed Speed(m/min):
|
18
|
Port:
|
Qingdao Or Shanghai
|
|
Condition:
|
New
|
|
Spindle Taper:
|
BT40
|
|
No. Of Spindles:
|
Single
|
|
Type:
|
VERTICAL
|
|
Dimension(L*W*H):
|
1900*1400*2100
|
|
Weight (T):
|
2.4 T
|
|
Table Size (mm):
|
800*260
|
|
Number Of Axes:
|
3, 4, 5
|
|
Table Travel (X) (mm):
|
450
|
|
Table Travel (Y) (mm):
|
320
|
|
Table Travel (Z) (mm):
|
420
|
|
Positioning Accuracy (mm):
|
±0.01
|
|
Repeatability (X/Y/Z) (mm):
|
±0.003
|
|
Range Of Spindle Speed(r.p.m):
|
1 - 8000 R.p.m
|
|
Spindle Motor Power(kW):
|
3.7/5.5
|
|
Max. Table Load(kg):
|
200 Kg
|
|
Min. Time Of Tool Change(s):
|
7
|
|
Tool Magazine Capacity:
|
16, 10, 12
|
|
Key Selling Points:
|
High Safety Level
|
|
Warranty:
|
1 Year
|
|
Voltage:
|
380V 50HZ /220V 60 HZ
|
|
Marketing Type:
|
New Product 2020
|
|
Machinery Test Report:
|
Provided
|
|
Video Outgoing-inspection:
|
Provided
|
|
Warranty Of Core Components:
|
1 Year
|
|
CNC Or Not:
|
CNC System
|
|
After-sales Service Provided:
|
Engineers Available To Service Machinery Overseas
|
|
Travel Of X Axis(mm):
|
450
|
|
Travel Of Y Axis(mm):
|
320
|
|
Travel Of Z Axis(mm):
|
420
|
|
Max Speed Of Spindle (Rpm):
|
60-8000
|
|
Positioning Accuracy:
|
±0.01
|
|
Local Service Location:
|
None
|
|
Applicable Industries:
|
Building Material Shops, Machinery Repair Shops, Manufacturing Plant
|
|
Showroom Location:
|
None
|
|
Core Components:
|
Motor
|
|
Feed Speed(mm/min):
|
1 - 4000 Mm/min
|
|
Rapid Feed Speed(m/min):
|
18
|
|
Port:
|
Qingdao Or Shanghai
|
| Table Size | 800×260 mm |
| Max Load | 400 kg |
| X-axis Travel | 450 mm |
| Y-axis Travel | 320 mm |
| Z-axis Travel | 420 mm |
| Spindle Speed | 60-8000 RPM |
| Positioning Accuracy | ±0.01 mm |
| Repeatability | ±0.005 mm |
| Tool Capacity | 12 tools |
| Machine Weight | 2400 kg |
| Dimensions | 2100×1760×1960 mm |
