Product Details
Place of Origin: China
Brand Name: Luyoung
Certification: CE
Model Number: VMC1270
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: 52000-60000
Packaging Details: Fumigation-free plywood
Delivery Time: 45 working days
Payment Terms: T/T, , L/C, Western Union
Supply Ability: 100sets
| Specification | Value |
|---|---|
| Size of worktable (length×width) | 1300×700 mm |
| T slot | 7-18×100 mm |
| Max loading weight on worktable | 900 KG |
| X-Axis travel | 1200 mm |
| Y-Axis travel | 700 mm |
| Z-Axis travel | 700 mm |
| Distance between spindle nose and table | 120-720 mm |
| Distance between spindle center and column | 835 mm |
| Spindle taper | BT40 |
| Max. spindle speed | 8000/10000/12000 rpm |
| Spindle motor power | 11-15 Kw |
| Rapid feeding speed: X,Y,Z axis | 24/24/24 m/min (linear guideway) |
| Fast cutting speed | 10 m/min |
| Positional accuracy | ±0.005 mm |
| Repeat positional accuracy | ±0.003 mm |
| Auto Tool changer type | 24 arm type auto tool change |
| X/Y/Z linear guide way | φ4012 |
| Max.tool weight | 7500 KG |
| Tool changing time (tool-to-tool) | 2.5 sec |
| Air pressure | 0.6 Mpa |
| Machine weight | 7500 KG |
| Overall size | 3340×2800×2700 mm |
| Voltage | 380v 3 phase |
