Product Details
Place of Origin: SHANDONG
Brand Name: cnc lathe machine
Certification: CE
Model Number: CK6140
Payment & Shipping Terms
Minimum Order Quantity: 1/SET
Price: $6900-$9000
Packaging Details: non-fumigation wooden box
Delivery Time: 30DAYS
Payment Terms: T/T
Supply Ability: 30/SET
|
Spindle Speed Ranges:
|
100~1600r/min
|
Distance Between Centres:
|
750mm
|
Coolant System:
|
Yes
|
Positioning Accuracy:
|
0.01
|
Cnc Or Not:
|
Cnc
|
Spindle Head Type:
|
A2-5
|
Machine Dimension:
|
2/2.3*1.5*1.7
|
Cnc Control:
|
GSK Or FANUC
|
Tailstock Shaft Diameter:
|
95mm
|
Spindle Head:
|
A2-6
|
Turret Type:
|
4/6/8 Station Turret
|
Spindle Motor Power:
|
7.5kW
|
Tailstock Quill Travel:
|
250
|
Spindle Motor:
|
5.5kw
|
Tool Post Stations:
|
6, 4
|
Condition:
|
New
|
Through Spindle Hole:
|
50mm
|
Spindle Bore:
|
38mm
|
Z-Axis Travel:
|
500mm
|
Tailstock Shaft Travel:
|
250mm
|
Cnc Control System:
|
GSK
|
|
Spindle Speed Ranges:
|
100~1600r/min
|
|
Distance Between Centres:
|
750mm
|
|
Coolant System:
|
Yes
|
|
Positioning Accuracy:
|
0.01
|
|
Cnc Or Not:
|
Cnc
|
|
Spindle Head Type:
|
A2-5
|
|
Machine Dimension:
|
2/2.3*1.5*1.7
|
|
Cnc Control:
|
GSK Or FANUC
|
|
Tailstock Shaft Diameter:
|
95mm
|
|
Spindle Head:
|
A2-6
|
|
Turret Type:
|
4/6/8 Station Turret
|
|
Spindle Motor Power:
|
7.5kW
|
|
Tailstock Quill Travel:
|
250
|
|
Spindle Motor:
|
5.5kw
|
|
Tool Post Stations:
|
6, 4
|
|
Condition:
|
New
|
|
Through Spindle Hole:
|
50mm
|
|
Spindle Bore:
|
38mm
|
|
Z-Axis Travel:
|
500mm
|
|
Tailstock Shaft Travel:
|
250mm
|
|
Cnc Control System:
|
GSK
|
| Spindle Speed Ranges | 100~1600r/min |
|---|---|
| Distance Between Centres | 750mm |
| Positioning Accuracy | 0.01 |
| Spindle Head Type | A2-5/A2-6 |
| Machine Dimension | 2/2.3*1.5*1.7m |
| CNC Control | GSK or FANUC |
| Spindle Motor Power | 7.5kW |
| Through Spindle Hole | 50mm |
| Z-Axis Travel | 500mm |
| Maximum Rotary Diameter (Bed) | Φ400mm |
|---|---|
| Maximum Rotary Diameter (Tray) | Φ180mm |
| Maximum Machining Length | 850/1500mm |
| Maximum Stroke (X/Z) | X:220mm / Z:1050/1600mm |
| Turret Type | 4/6/8 Station Turret |
| Tailstock Shaft Diameter | 95mm |
| Tailstock Quill Travel | 250mm |
