Product Details
Place of Origin: Shandong, China
Brand Name: luyoung
Model Number: tck630
Payment & Shipping Terms
Price: $35,000.00/sets >=1 sets
Packaging Details: non-fumigation wooden box
Delivery Time: 45 working days
Payment Terms: L/C, T/T
Supply Ability: 30/SET
|
Max. Length Of Workpiece (mm):
|
500
|
Structure:
|
Slant Bed Lathe
|
Machining Capacity:
|
Medium Duty
|
Width Of Bed (mm):
|
600 Mm
|
Spindle Motor Power(kW):
|
11
|
No. Of Spindles:
|
Single
|
Travel (X Axis)(mm):
|
340 Mm
|
Travel (Z Axis)(mm):
|
1000 Mm
|
Positioning Accuracy (mm):
|
±0.006
|
Repeatability (X/Y/Z) (mm):
|
±0.015
|
Voltage:
|
380v 3 Phase
|
Tool Post Stations:
|
12
|
Weight (KG):
|
5700
|
Key Selling Points:
|
High Safety Level
|
Machinery Test Report:
|
Provided
|
Video Outgoing-inspection:
|
Provided
|
Warranty Of Core Components:
|
1 Year
|
CNC Or Not:
|
CNC
|
Automatic Grade:
|
Automatic
|
Max.swing Over Bed:
|
630mm
|
Cross Slide Length:
|
1000mm
|
Lathe Bed Straucture:
|
3 Jaw Manual Chuck
|
Control System:
|
SIEMENS GSK FANUC (optional)
|
Spindle Nose:
|
A2-8
|
Spindle Bore:
|
87mm
|
Condition:
|
New
|
Toolpost Brand:
|
Hongda
|
Applicable Industries:
|
Machinery Repair Shops, Manufacturing Plant, Retail
|
Showroom Location:
|
None
|
Core Components:
|
Bearing, Gear
|
Max. Spindle Speed (r.p.m):
|
3000 R.p.m
|
Spindle Bore(mm):
|
88
|
Max. Turned Length (mm):
|
500
|
|
Max. Length Of Workpiece (mm):
|
500
|
|
Structure:
|
Slant Bed Lathe
|
|
Machining Capacity:
|
Medium Duty
|
|
Width Of Bed (mm):
|
600 Mm
|
|
Spindle Motor Power(kW):
|
11
|
|
No. Of Spindles:
|
Single
|
|
Travel (X Axis)(mm):
|
340 Mm
|
|
Travel (Z Axis)(mm):
|
1000 Mm
|
|
Positioning Accuracy (mm):
|
±0.006
|
|
Repeatability (X/Y/Z) (mm):
|
±0.015
|
|
Voltage:
|
380v 3 Phase
|
|
Tool Post Stations:
|
12
|
|
Weight (KG):
|
5700
|
|
Key Selling Points:
|
High Safety Level
|
|
Machinery Test Report:
|
Provided
|
|
Video Outgoing-inspection:
|
Provided
|
|
Warranty Of Core Components:
|
1 Year
|
|
CNC Or Not:
|
CNC
|
|
Automatic Grade:
|
Automatic
|
|
Max.swing Over Bed:
|
630mm
|
|
Cross Slide Length:
|
1000mm
|
|
Lathe Bed Straucture:
|
3 Jaw Manual Chuck
|
|
Control System:
|
SIEMENS GSK FANUC (optional)
|
|
Spindle Nose:
|
A2-8
|
|
Spindle Bore:
|
87mm
|
|
Condition:
|
New
|
|
Toolpost Brand:
|
Hongda
|
|
Applicable Industries:
|
Machinery Repair Shops, Manufacturing Plant, Retail
|
|
Showroom Location:
|
None
|
|
Core Components:
|
Bearing, Gear
|
|
Max. Spindle Speed (r.p.m):
|
3000 R.p.m
|
|
Spindle Bore(mm):
|
88
|
|
Max. Turned Length (mm):
|
500
|
| Specification | Value |
|---|---|
| Max. Swing Over Bed | 630mm |
| Max. Processing Length | 460mm |
| Cross Slide Length | 1000mm |
| Spindle Bore | 87mm |
| Spindle Speed Range | 50-3000 R/min |
| X Axis Travel | 340mm |
| Z Axis Travel | 1000mm |
| Positioning Accuracy | ±0.006mm |
| Repositioning Accuracy | ±0.015mm |
| Machine Dimensions (L×W×H) | 3650×1870×2100mm |
| Net Weight | 5700kg |
