Product Details
Place of Origin: SHANDONG
Brand Name: cnc lathe machine
Certification: CE
Model Number: CK61125
Payment & Shipping Terms
Minimum Order Quantity: 1/SET
Price: $25000-$38000
Packaging Details: non-fumigation wooden box
Delivery Time: 30DAYS
Payment Terms: T/T
Supply Ability: 30/SET
|
Through Bar Diameter:
|
Ø104/(optional Ø130)
|
Tool Post Stations:
|
8, 6, 4
|
Distance Between Centres:
|
3000mm
|
Machine Dimension:
|
2/2.3*1.5*1.7
|
Positioning Accuracy:
|
0.01
|
Cnc Or Not:
|
Cnc
|
Spindle Speed Ranges:
|
100~1600r/min
|
Precision:
|
High Precision
|
Total Power:
|
15kw
|
Condition:
|
New
|
Max Processing Length:
|
1500mm
|
Tailstock Shaft Diameter:
|
95mm
|
Function:
|
Metal Machining
|
Number Of Axes:
|
2
|
Bed Type:
|
Flat Bed
|
Structure:
|
Flat Bed Lathe
|
Coolant System:
|
Automatic
|
Control System:
|
CNC
|
|
Through Bar Diameter:
|
Ø104/(optional Ø130)
|
|
Tool Post Stations:
|
8, 6, 4
|
|
Distance Between Centres:
|
3000mm
|
|
Machine Dimension:
|
2/2.3*1.5*1.7
|
|
Positioning Accuracy:
|
0.01
|
|
Cnc Or Not:
|
Cnc
|
|
Spindle Speed Ranges:
|
100~1600r/min
|
|
Precision:
|
High Precision
|
|
Total Power:
|
15kw
|
|
Condition:
|
New
|
|
Max Processing Length:
|
1500mm
|
|
Tailstock Shaft Diameter:
|
95mm
|
|
Function:
|
Metal Machining
|
|
Number Of Axes:
|
2
|
|
Bed Type:
|
Flat Bed
|
|
Structure:
|
Flat Bed Lathe
|
|
Coolant System:
|
Automatic
|
|
Control System:
|
CNC
|
| Attribute | Value |
|---|---|
| Through Bar Diameter | Ø104/(optional Ø130) |
| Tool Post Stations | 8, 6, 4 |
| Distance Between Centres | 3000mm |
| Machine Dimension | 2/2.3*1.5*1.7 |
| Positioning Accuracy | 0.01 |
| Spindle Speed Ranges | 100~1600r/min |
| Total Power | 15kw |
| Max Processing Length | 1500mm |
| Tailstock Shaft Diameter | 95mm |
| Item | CK61125*1500 | CK61125*2000 | CK61125*3000 |
|---|---|---|---|
| Max. swing over bed (mm) | Φ1250 | Φ1250 | Φ1250 |
| Max. swing dia. over cross slide(mm) | Φ970 | Φ970 | Φ970 |
| Max.processing length(mm) | 1500 | 2000 | 3000 |
