Product Details
Place of Origin: China
Brand Name: Luyoung
Certification: CE
Model Number: CK6150x1500
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: USD15800-USD17200
Packaging Details: Fumigation-free plywood
Delivery Time: 45 working days
Payment Terms: L/C, T/T
Supply Ability: 100sets
| Item | CK6150A |
|---|---|
| Max. swing dia. over bed | 500mm |
| Max. swing dia. over cross slide | 280mm |
| Processing length | 750mm/1000mm/1500mm |
| Width of the bed | 400mm |
| Dia. of spindle | 82mm |
| Spindle taper | 1:20/90 |
| Spindle nose | Type of spindle head D-8 |
| Spindle speed | 15-1500rpm |
| Spindle speed step | step-less |
| Chuck size | 250mm |
| Tool holder | 4 station |
| Tool bar section | 25X25mm |
| Main motor power | 7.5KW |
| X/Z axis position accuracy | 0.02/0.025mm |
| X/Z axis repeatability | 0.01/0.012mm |
| X/Z axis travel | 360/750mm/1000mm/1500mm |
| X/Z axis fast feeding speed | 8/10 M/MIN |
| Tailstock sleeve travel | 150mm |
| Tailstock taper | MT5 |
| Dimension | 2410/2660/3160*1560*1730mm |
| Weight | 2800/3200/3500kg |
