Product Details
Place of Origin: CHINA
Brand Name: Luyoung
Certification: CE
Model Number: M7140*1600
Payment & Shipping Terms
Minimum Order Quantity: 1/set
Price: $17000
Packaging Details: non-fumigation wooden box
Delivery Time: 30days
Payment Terms: T/T, D/P, D/A, Western Union, MoneyGram
Supply Ability: 10/set
|
Automatic Grade:
|
Automatic
|
Cnc Or Not:
|
Normal
|
Marketing Type:
|
New Product 2024
|
Showroom Location:
|
None
|
Cylindrical Grinder Type:
|
Flat Bed
|
Power Source:
|
Electric
|
Color:
|
Blue
|
Production Capacity:
|
High,adjustable
|
Machinery Test Report:
|
Provided
|
Warranty Of Core Components:
|
1 Year
|
Specification:
|
2.8-6.5 T
|
|
Automatic Grade:
|
Automatic
|
|
Cnc Or Not:
|
Normal
|
|
Marketing Type:
|
New Product 2024
|
|
Showroom Location:
|
None
|
|
Cylindrical Grinder Type:
|
Flat Bed
|
|
Power Source:
|
Electric
|
|
Color:
|
Blue
|
|
Production Capacity:
|
High,adjustable
|
|
Machinery Test Report:
|
Provided
|
|
Warranty Of Core Components:
|
1 Year
|
|
Specification:
|
2.8-6.5 T
|
| Worktable | |
|---|---|
| Size (Length×Width) | 1600×400 mm |
| Longitudinal motion stroke | 1700 mm |
| T-slot quantity×width | 3×18 mm |
| Longitudinal velocity (stepless) | 3-25 m/min |
| Distance from table surface to spindle center | 570 mm |
| Grinding Head | |
| Horizontal stroke (manual/hydraulic) | 440 mm |
| Vertical stroke (manual) | 400 mm |
| Size (OD×W×ID) | 350×400×127 mm |
| Grinding wheel spindle speed | 1440 rpm |
| Vertical feed hand wheel per movement | 0.01 mm |
| Vertical feed wheel movement per lap | 1 mm |
| Motor Specifications | |
| Total motor power | 12 kW |
| Grinding head motor | 7.5 kW at 1440 r/min |
| Fast lifting motor | 0.37 kW at 1440 r/min |
| Oil pump motor | 4 kW at 960 r/min |
| Cooling pump motor | 0.125 kW |
| Automatic Grade | Automatic |
| CNC or Not | Normal |
| Marketing Type | New Product 2024 |
| Cylindrical Grinder Type | Flat bed |
| Power Source | Electric |
| Color | Blue |
| Production Capacity | High, adjustable |
| Warranty of core components | 1 Year |
| Specification | 2.8-6.5 T |
