Product Details
Place of Origin: CHINA
Brand Name: Luyoung
Certification: CE
Model Number: M7140*1000
Payment & Shipping Terms
Minimum Order Quantity: 1/set
Price: $12000
Packaging Details: non-fumigation wooden box
Delivery Time: 30days
Payment Terms: T/T, D/P, D/A, Western Union, MoneyGram
Supply Ability: 10/set
|
Automatic Grade:
|
Automatic
|
Cnc Or Not:
|
Normal
|
Marketing Type:
|
New Product 2024
|
Showroom Location:
|
None
|
Cylindrical Grinder Type:
|
Flat Bed
|
Power Source:
|
Electric
|
Color:
|
Blue
|
Production Capacity:
|
High,adjustable
|
Machinery Test Report:
|
Provided
|
Warranty Of Core Components:
|
1 Year
|
Specification:
|
2.8-6.5 T
|
|
Automatic Grade:
|
Automatic
|
|
Cnc Or Not:
|
Normal
|
|
Marketing Type:
|
New Product 2024
|
|
Showroom Location:
|
None
|
|
Cylindrical Grinder Type:
|
Flat Bed
|
|
Power Source:
|
Electric
|
|
Color:
|
Blue
|
|
Production Capacity:
|
High,adjustable
|
|
Machinery Test Report:
|
Provided
|
|
Warranty Of Core Components:
|
1 Year
|
|
Specification:
|
2.8-6.5 T
|
| Parameter | Unit | Value |
|---|---|---|
| Size(LengthxWidth) | mm | 1000x400 |
| Longitudinal motion stroke | mm | 1100 |
| T-solt quantityx width(mm) | mm | 3x18 |
| Longitudinal velocity(stepless) | m/min | 3-25 |
| Distance from table surface to spindle center | mm | 600 |
| Parameter | Unit | Value |
|---|---|---|
| The stroke of grinding head (horizontal) | mm | 440 |
| The stroke of grinding head (vertical) | mm | 400 |
| Size(ODxWxID) | mm | 350x40x127 |
| Speed of grinding wheel spindle | rpm | 1440 |
| Vertical feed hand wheel per movement | mm | 0.01 |
| Vertical feed wheel movement per lap | mm | 1 |
| Total motor power | kw | 8.99 |
| Component | Parameter | Unit | Value |
|---|---|---|---|
| Grinding head motor | Power | kw | 5.5 |
| Speed | r/min | 1440 | |
| Fast lifting motor | Power | kw | 0.37 |
| Speed | r/min | 1440 | |
| Oil pump motor | Power | kw | 3 |
| Speed | r/min | 960 | |
| Cooling pump motor | Power | kw | 0.125 |
